DRMOT: A Dataset and Framework for RGBD Referring Multi-Object Tracking
Organizations: Huazhong University of Science and Technology · South-Central Minzu University
Abstract
Referring Multi-Object Tracking (RMOT) aims to track specific targets based on language descriptions, playing a vital role in interactive AI systems such as robotics and autonomous driving. However, existing RMOT methods rely exclusively on 2D RGB observations. Since similar 2D projections can correspond to different 3D configurations, the available observations may not uniquely determine the referred targets. This creates a fundamental mismatch between the task requirements and the available input. To advance research on the DRMOT task, we construct DRSet, a dataset tailored for the DRMOT task. DRSet comprises 2,076 referring expressions over 186 RGB-D source sequences. It features synchronized RGB images and depth maps paired with language descriptions, including explicit depth-dependent descriptions, to systematically evaluate spatial-semantic detection and tracking capabilities. Furthermore, we propose DRTrack, an MLLM-guided depth-referring tracking framework. DRTrack leverages a Geometric-Aware GRPO fine-tuned Multimodal Large Language Model (MLLM) to achieve precise spatial-semantic detection from joint L+RGB+D inputs, while incorporating explicit depth cues to enforce robust trajectory association. Extensive experiments on the DRSet dataset demonstrate the effectiveness of our framework. Our dataset and code will be available at https://github.com/chen-si-jia/DRMOT.
Figures & tables
| Tracking Dataset | Language | RGB | Depth | Sequences | Expressions | Avg.Words |
| Refer-KITTI [ 6 ] | ✓ | ✓ | ✗ | 18 | 818 | 49 |
| Refer-Dance [ 26 ] | ✓ | ✓ | ✗ | 65 | 1.9K | 25 |
| LaMOT [ 30 ] | ✓ | ✓ | ✗ | 62 | 145 | 9 |
| CDTB [ 33 ] | ✗ | ✓ | ✓ | 80 | – | – |
| DepthTrack [ 34 ] | ✗ | ✓ | ✓ | 200 | – | – |
| ARKitTrack [ 7 ] | ✗ | ✓ | ✓ | 300 | – | – |
| Subject Type | Attribute Dimension | Example Attribute Values |
|---|---|---|
| Human | Clothing | Clothing color, clothing type, accessories |
| Hand-held objects | Backpack, basketball, umbrella, etc. | |
| Gender / Age | Male, female, child | |
| Actions | Waving, walking, eating, standing, etc. | |
| Scene interaction | Leaving, approaching | |
| Spatial position | Right side, front, back |
| Modality | Method | Venue | HOTA↑ | DetA↑ | AssA↑ | DetRe↑ | DetPr↑ | AssRe↑ | AssPr↑ | LocA↑ |
|---|---|---|---|---|---|---|---|---|---|---|
| L-RGB | TransRMOT [ 6 ] | CVPR 2023 | 1.16 | 0.24 | 5.79 | 0.26 | 2.57 | 5.90 | 90.28 | 75.00 |
| L-RGB | TempRMOT [ 23 ] | ArXiv 2024 | 2.75 | 0.72 | 10.58 | 0.82 | 5.28 | 11.94 | 63.42 | 75.07 |
| L-RGB | YOLOX [ 41 ] +ByteTrack [ 12 ] + iKUN [ 26 ] | CVPR 2024 | 7.89 | 2.87 | 21.78 | 4.70 | 6.78 | 25.48 | 62.27 | 77.42 |
| L-RGB | YOLOX [ 41 ] +OC-SORT [ 13 ] + iKUN [ 26 ] | CVPR 2024 | 8.36 | 3.00 | 23.49 | 4.66 | 7.63 | 27.30 | 65.99 | 78.32 |
| L-RGB | CRTracker [ 25 ] | AAAI 2025 | 8.23 | 2.67 | 27.25 | 3.85 | 7.79 | 29.39 | 66.16 | 72.63 |
| L-RGB | DKGTrack [ 42 ] | ICCV 2025 | 2.99 | 0.42 | 21.71 | 0.44 | 12.71 | 22.28 | 75.55 | 75.46 |
| MLLMs | Metrics | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Name | Size | HOTA↑ | DetA↑ | AssA↑ | DetRe↑ | DetPr↑ | AssRe↑ | AssPr↑ | LocA↑ | FPS↑ | AES↑ |
| DeepSeek-VL [ 38 ] | 7B | 9.76 | 9.79 | 10.53 | 19.49 | 14.32 | 12.43 | 39.65 | 63.46 | 5.63 | 8.51 |
| InternVL3.5 [ 46 ] | 8B | 5.61 | 6.49 | 5.29 | 9.20 | 15.82 | 5.78 | 49.86 | 66.28 | 2.34 | 4.51 |
| LLaVA-NEXT [ 37 ] | 8B | 14.37 | 14.24 | 16.26 | 27.05 | 20.67 | 18.92 | 50.11 | 69.75 | 4.71 | 10.87 |
| Qwen2.5-VL [ 8 ] | 3B | 11.45 | 8.26 | 20.14 | 11.69 | 20.08 | 22.22 | 56.48 | 71.51 | 5.83 | 9.67 |
| Qwen2.5-VL [ 8 ] | 7B | 17.70 | 18.76 | 18.06 | 41.71 | 23.23 | 21.13 | 50.02 | 72.76 | 3.75 | 12.01 |
| Settings | Metrics | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Input Data | Association | GRPO | HOTA↑ | DetA↑ | AssA↑ | DetRe↑ | DetPr↑ | AssRe↑ | AssPr↑ | LocA↑ |
| L+RGB | SORT | ✗ | 11.45 | 8.26 | 20.14 | 11.69 | 20.08 | 22.22 | 56.48 | 71.51 |
| L+RGB+D | SORT | ✗ | 11.23 | 7.82 | 20.26 | 10.88 | 19.92 | 22.46 | 56.88 | 71.68 |
| L+RGB | Ours | ✗ | 13.29 | 8.26 | 24.97 | 10.35 | 25.95 | 29.91 | 51.62 | 71.96 |
| L+RGB+D | Ours | ✗ | 12.75 | 7.70 | 24.66 | 9.58 | 25.40 | 29.80 | 51.90 | 72.12 |
| L+RGB | SORT | ✓ | 15.62 | 14.84 | 17.84 | 45.33 | 16.91 | 21.08 | 47.92 | 72.40 |
| Reward | Metrics | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| HOTA↑ | DetA↑ | AssA↑ | DetRe↑ | DetPr↑ | AssRe↑ | AssPr↑ | LocA↑ | ||
| ✓ | ✗ | 27.28 | 22.01 | 34.78 | 34.23 | 32.84 | 48.24 | 44.95 | 71.79 |
| ✗ | ✓ | 27.10 | 21.94 | 34.46 | 35.53 | 31.56 | 47.25 | 45.13 | 71.73 |
| ✓ | ✓ | 28.25 | 22.87 | 35.90 | 34.53 | 34.50 | 49.88 | 45.68 | 71.81 |
| Multimodal Large Language Models (MLLMs) | Input Data | Fusion Weight | Metrics | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Name | Size | RL Fine-tuning | HOTA↑ | DetA↑ | AssA↑ | DetRe↑ | DetPr↑ | AssRe↑ | AssPr↑ | LocA↑ | ||
| Qwen2.5-VL-3B-Instruct | 3B | ✓ (GRPO) | L+RGB+D | 0.0 | 28.18 | 22.80 | 35.85 | 34.47 | 34.39 | 49.95 | 45.31 | 71.79 |
| Qwen2.5-VL-3B-Instruct | 3B | ✓ (GRPO) | L+RGB+D | 0.1 | 28.24 | 22.86 | 35.89 | 34.53 | 34.47 | 49.88 | 45.67 | 71.81 |
| Qwen2.5-VL-3B-Instruct | 3B | ✓ (GRPO) | L+RGB+D | 0.2 | 28.23 | 22.87 | 35.87 | 34.54 | 34.49 | 49.84 | 45.65 | 71.81 |
| Qwen2.5-VL-3B-Instruct | 3B | ✓ (GRPO) | L+RGB+D | 0.4 | 28.21 | 22.82 | 35.89 | 34.53 | 34.38 | 49.88 | 45.68 | 71.81 |
| Qwen2.5-VL-3B-Instruct | 3B | ✓ (GRPO) | L+RGB+D | 0.5 | 28.10 | 22.67 | 35.84 | 34.56 | 34.03 | 49.76 | 45.72 | 71.81 |
| Metrics | ||||||||
|---|---|---|---|---|---|---|---|---|
| HOTA↑ | DetA↑ | AssA↑ | DetRe↑ | DetPr↑ | AssRe↑ | AssPr↑ | LocA↑ | |
| 1 | 20.54 | 19.31 | 23.13 | 35.73 | 26.29 | 29.34 | 46.99 | 71.66 |
| 5 | 26.95 | 22.00 | 34.05 | 34.84 | 32.29 | 46.18 | 46.41 | 71.79 |
| 10 | 27.98 | 22.54 | 35.75 | 34.60 | 33.69 | 49.51 | 45.83 | 71.80 |
| 15 | 28.17 | 22.78 | 35.84 | 34.54 | 34.29 | 49.79 | 45.66 | 71.82 |
| 30 | 28.24 | 22.87 | 35.90 | 34.53 | 34.50 | 49.88 | 45.68 | 71.81 |
| Depth Setting | Metrics | |||
|---|---|---|---|---|
| HOTA↑ | DetA↑ | AssA↑ | AssRe↑ | |
| Gaussian 20 mm | 28.23 | 22.88 | 35.83 | 49.83 |
| Gaussian 50 mm | 28.24 | 22.88 | 35.84 | 49.81 |
| Gaussian 100 mm | 28.22 | 22.87 | 35.80 | 49.80 |
| Multiplicative 5% | 28.23 | 22.87 | 35.81 | 49.80 |
| Multiplicative 10% | 28.23 | 22.88 | 35.85 | 49.87 |
| Interval | Metrics | ||||||
|---|---|---|---|---|---|---|---|
| (frames) | HOTA↑ | DetA↑ | AssA↑ | DetRe↑ | AssRe↑ | FPS↑ | AES↑ |
| 1 | 38.36 | 32.49 | 45.89 | 48.07 | 60.61 | 0.49 | 12.88 |
| 5 | 33.76 | 27.80 | 41.89 | 40.96 | 56.21 | 2.42 | 17.46 |
| 10 | 28.25 | 22.87 | 35.90 | 34.53 | 49.88 | 4.82 | 18.16 |
| 20 | 21.76 | 16.95 | 29.05 | 26.69 | 42.12 | 9.15 | 17.52 |
| 30 | 19.14 | 14.38 | 26.80 | 23.13 | 39.21 | 12.94 | 17.36 |
