RoboStream: Weaving Spatio-Temporal Reasoning with Memory in Vision-Language Models for Robotics

Robotic manipulation in open-world environments requires reasoning across semantics, geometry, and long-horizon action dynamics. Existing hierarchical Vision-Language-Action (VLA) frameworks typically use 2D representations to connect high-level reasoning with low-level control, but lack depth awareness and temporal consistency, limiting robustness in complex 3D scenes. We propose ST-VLA, a hierarchical VLA framework using a unified 3D-4D representation to bridge perception and action. ST-VLA converts 2D guidance into 3D trajectories and generates smooth spatial masks that capture 4D spatio-temporal context, providing a stable interface between semantic reasoning and continuous control. To enable effective learning of such representations, we introduce ST-Human, a large-scale human manipulation dataset with 14 tasks and 300k episodes, annotated with 2D, 3D, and 4D supervision via a semi-automated pipeline. Using ST-Human, we train ST-VLM, a spatio-temporal vision-language model that generates spatially grounded and temporally coherent 3D representations to guide policy execution. The smooth spatial masks focus on task-relevant geometry and stabilize latent representations, enabling online replanning and long-horizon reasoning. Experiments on RLBench and real-world manipulation tasks show that \method significantly outperforms state-of-the-art baselines, improving zero-shot success rates by 44.6% and 30.3%. These results demonstrate that offloading spatio-temporal reasoning to VLMs with unified 3D-4D representations substantially improves robustness and generalization for open-world robotic manipulation. Project website: https://oucx117.github.io/ST-VLA/.

Vision-language-action (VLA) models have achieved great success on general robotic tasks, but still face challenges in fine-grained spatiotemporal manipulation. Typically, existing methods mainly embed spatiotemporal knowledge into visual and action representations, and directly perform a cross-modal mapping for step-level action prediction. However, such spatiotemporal reasoning remains largely implicit, making it difficult to handle multiple sequential behaviors with explicit spatiotemporal boundaries. In this work, we propose ST-$π$, a structured spatiotemporal VLA model for robotic manipulation. Our model is guided by two key designs: 1) Spatiotemporal VLM. We encode 4D observations and task instructions into latent spaces, and feed them into the LLM to generate a sequence of causally ordered chunk-level action prompts consisting of sub-tasks, spatial grounding and temporal grounding. 2) Spatiotemporal action expert. Conditioned on chunk-level action prompts, we design a structured dual-generator guidance to jointly model spatial dependencies and temporal causality, thus predicting step-level action parameters. Within this structured framework, the VLM explicitly plans global spatiotemporal behavior, and the action expert further refines local spatiotemporal control. In addition, we propose a real-world robotic dataset with structured spatiotemporal annotations for fine-tuning. Extensive experiments have been conducted to demonstrate the effectiveness of our model. Our code link: https://github.com/chuanhaoma/ST-pi.

Temporal modeling is essential for robotic manipulation, as effective control requires both memory of past interactions and imagination of future states. However, most VLA models rely primarily on the current observation and therefore struggle with long-horizon, temporally dependent tasks. Cognitive science suggests that humans rely on working memory to buffer short-lived context, the hippocampal system to preserve episodic memory of past experience, and internal models to imagine possible future state evolution. Inspired by these mechanisms, we propose MemoryVLA++, a full temporal modeling framework that equips VLA models with memory and imagination for robotic manipulation. A pretrained VLM encodes the current observation into perceptual and cognitive tokens, forming working memory. These tokens query a Perceptual-Cognitive Memory Bank to retrieve relevant historical context. This bank stores low-level details and high-level semantics from past interactions, and is updated through redundancy-aware consolidation. A world model imagines future states in a denoising latent space, and the imagined latents are integrated under memory guidance to form full temporal-aware tokens. The resulting tokens condition a diffusion action expert to predict temporally consistent action sequences. We conduct extensive experiments on 5 simulation benchmarks and 3 categories of real-robot tasks across 3 robots, covering general manipulation, long-horizon temporal tasks, robustness, and generalization. Our method achieves strong performance across Libero, SimplerEnv, Mikasa-Robo, Calvin, Libero-Plus, and diverse real-robot tasks, validating the effectiveness of full temporal modeling with memory and imagination. For example, on real robots, it achieves +9%, +26%, +28% gains on general, memory-dependent, and imagination-dependent tasks. Project Page: https://shihao1895.github.io/MemoryVLA-PP-Web
